问: How do I know the power supply is the single rail type or multi rail type?(2022/3/1) 答: You can check the label on the power supply, it show the detailed specification of the power supply.
If you only see one "+12V” on your power supply, it means your power supply is "single rail” design.
For example.
If you only see multiple"+12V” on your power supply, it means your power supply is "multi rail” design.
问: How do I check if the system can support Secure Boot?(2021/10/1) 答: In order to use Secure Boot, the drive with the operating system must use GPT partition style. Please refer to below steps to check the partition style.
Step 1: Right-click the Windows button on the desktop and select "Disk Management”.
Step 2: Right-click the disk where Windows is installed and select the "Properties”.
Step 3: Click the "Volumes” tab and check if the partition style is "GPT”.
Step 4: If the partition style is "MBR”, please make a backup of important data on the system and refer to steps 5 - 7 to convert the partition style to GPT.
Step 5: Type "CMD" in the Windows search bar, right-click on "Command Prompt” and choose to run as administrator.
Step 6: Type the command "mbr2gpt /convert /allowFullOS” to convert the partition style and press [Enter].
Step 7: Restart the system and the BIOS Mode/Partition style will be converted to UEFI/GPT.
问: How to enable C.A.M in the BIOS? Also known as Resizable BAR.(2021/4/1) 答:
Step 1: On the ASRock website please find the BIOS download page for you motherboard.
Check the descriptions to see if C.A.M. is supported already.
Intel 500-series models support C.A.M. since the first version.
Step 2: While the system is starting press "DEL” to boot into BIOS setup and go to BIOS\Boot\CSM.
If you cannot find the CSM menu then please set "Fast Boot” to "Disabled”.
Step 3: In BIOS\Boot\CSM please set "CSM” to "Disabled”.
Step 4: Go to BIOS\Advanced\Chipset Configuration and set "Above 4G Decoding” to "Enabled”.
Step 5: After step 4, the option "C.A.M” will appear below the option "Above 4G Decoding”.
Please set it to "Enabled”.
Step 6: Press "F10” to save the settings and restart the system.
问: 在 Windows 8 操作系统下使用 XFast USB 时,无法通过 ASMedia USB 3.0 接口复制文件。如何解决该问题?(2013/3/1) 答: 若要在 ASMedia USB 3.0 接口上使用 XFast USB,请安装 ASMedia USB 3.0 驱动程序,并使用 Windows 8 inbox驱动。
问: 当使用 Windows MCE 时,系统有时会自动被唤醒。我该如何解决这个问题?(2011/6/1) 答: 请参考下图来关闭 MCE 下的"Automatically download Windows Media Center data between the following times"项目。
(路径:MCE-> Task->Settings-> General->Automatic Download options-> Automatically download Windows Media Center data between the following time。)
问: 当我在Vista SP1下使用Adobe Acrobat Reader ver 7.08阅读PDF文件时,它会弹出错误信息:This program has some compatibility issue…(这个程序存在一些兼容性问题……),我该怎么办?(2008/4/28) 答: 请到Adobe网站下载最新版的Adobe Reader,并将它升级到8.1.2以上版本来修复这个问题。
问: 我在Windows® XP Professional x64 Edition下使用4 GB系统内存。为什么我在控制面板的电源选项里无法启用休眠?这里没有休眠选项卡!(2007/11/5) 答: Windows® XP Professional x64 Edition不支持系统内存大于4GB的休眠。请查阅微软知识库(Microsoft® Knowledge Base)了解详情: http://support.microsoft.com/kb/888575
问: 安装Windows® XP x64 Edition之后,在设备管理器中看到"Unsupported Standard Game Port"(不支持标准游戏接口)。并且没有感叹号"!"或错误提示信息。为什么?(2006/1/16) 答: Microsoft® Windows® XP x64 Edition不支持游戏接口。如果您想要在Windows® XP x64 Edition中使用游戏手柄或者操纵杆,请使用带USB接口的。
问: 我的主板是K7VT4A+和K7VM3。开机自检(POST)期间,它显示"Mac address are invalid in both CMOS and DMI. Press F1 to resume"(意即CMOS和DMI里的Mac地址均已失效。按F1恢复)。我应该做什么?(2004/12/15) 答: 请从下面的网址下载改写MAC地址的工具: https://www.asrock.com/support/Download/MacTool.asp
问: 我的操作系统是Windows XP(或者Windows 2000),并且我已经安装了XP Service Pack 1(Windows 2000 Service Pack 4)。但当我使用USB 2.0设备时,会显示"High-Speed devices is attached to a non-Hi-Speed port"(高速设备配备了非高速接口)。我怎么样才可以使用USB 2.0设备呢?(2004/10/15) 答: 请进入"device manager" (设备管理器)检查设备是否已正确安装。如果没有,请按下面的步骤操作。
1.右键点击有惊叹号标志的设备并选择"properties"(属性)。
问: 更新Windows XP service pack 2之后, 一些基准测试软件或程序不能正常运行。接下来我应该做什么?(2004/9/14) 答: 目前Windows XP service pack 2会引起一些不兼容的问题。关于service pack 2的不兼容问题,您可以查阅下面的微软网址:
http://support.microsoft.com/default.aspx?kbid=884130&product=windowsxpsp2
问: 当我将机箱上的POWER SW,POWER LED,RESET SW 和 HDD LED 等连线接到主板的PANEL1接口时,我发现连线的针孔与对应接口不能相匹配。我应该怎么办?(2004/3/15) 答: 请参看下面的图片。如果您原先的 POWER LED 两条连线接在针孔1和3(如Fig.1),请将其中一条移至中间的针孔2(如Fig.2)。然后参看Fig.3和Fig.4,按图示连接。
问: 我在华擎主板上使用外接网卡。网卡提供"Wake On LAN"连线接口。我可以将此连线接到主板上的相应接口吗?(2003/12/12) 答: 不需要将此连线接到主板,您仍然可以使用网卡的"Wake On LAN" 功能。要使用这个功能,请记得在BIOS里将"PCI Device Power On"选项设为enable。
问: 我怎样使用网络唤醒(Wake on LAN)功能?(2003/7/9) 答: 华擎主板均支持网络唤醒(Wake on LAN)。请在BIOS里的"Power"菜单下将"PCI Device Power On"一项设置为"enable"。然后保存更改并退出BIOS,请启动进入Windows操作系统后再关闭系统。
现在,你可以使用另一台电脑通过网络唤醒这台已经准备好的系统了。
